Automatic Adhesive Tape Dispenser

Model
ZCUT-9
Brand
KINGSING
Price
Inquiry
  1. Description
  2. Specification
  3. Application
  4. Wear Parts

This is a fully programmable tape dispenser equipped with a precise photoelectric cut-off blade controlled by two individual photocells. It does not require any tape's core support or shaft and enables to easily process two tapes simultaneously.

Applicable Material: insulating tape, transparent tape, PVC tape, double sticky tape, etc.
Cutting Length: 5 - 999mm
Tape Width: 6 - 60mm
Max. Tape OD: 300mm
Feeding Speed: 200mm/s
Power Supply: 220V/50Hz 110V/60Hz
Power Rating: 25W
Net. Weight: 2.5Kg
Dimension: 116(W) × 140(H) × 213(L) mm
