Hot Knife label Cutting Machine

Model
KS-C360
Brand
KINGSING
Price
Inquiry
  1. Description
  2. Specification
  3. Application
  4. Wear Parts

Features:

The care label cutting machine is especially designed for cutting care label and woven belt, it's able to cut material at a specified position with very high accuracy thanks to the color detecting sensor. Cutting is sealed neatly without fraying because hot knife melts the end of tape, and durability is very long because the bottom plate is fixed and only upper blade moves up & down.

Cutting Knife: Hot (No cold knife function)
Max. Cutting Width: 100mm
Cutting Length: 0-9999mm
Max. Blade Temp: 420℃
Cutting Speed: 6000pcs/hour
Power Supply: 220V/50Hz 110V/60Hz
Power Rating: 500W
Net Weight: 26Kg
Dimension: 410 × 525 × 430mm
