Rotary Blade Cable Stripping Machine KS-W70 Series belongs to the latest generation of automatic cutting and stripping machines. This model is compelling in the extremely broad range of processing they cover. With the simple, flexible touch screen, affordable price and minimal material used during setup, KS-W70 Series has quickly become a very popular type of stripping machines worldwide.
Download: (1)
| Model | KS-W701 | KS-W702 | KS-W703 |
| Stripping Diameter | 10~45mm | 10~20mm | 4~20mm |
| Stroke | 0~300mm | 0~20mm | 0~120mm |
| Stripping Method | Rotary Blade | ||
| Control System | PLC and Touch Screen | ||
| Program Storage | Max.68 groups | ||
| Power Supply | 220V/60Hz 110V/60Hz | ||
| Air Supply | 0.5~0.7Mpa | ||
| Power Rating | 200W | ||
| Stripping Accuracy | 0.1mm×Stripping Length | ||
| Speed | 1200~3000 pcs/hour | ||
| NET. Weight | 110Kg | ||
| Dimension | 1400*330*420mm | ||
Note：
The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.
Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
