Five Station Wire Spool Prefeeding Machine

Model
KS-W225
Brand
KINGSING
Price
Inquiry
  1. Description
  2. Specification
  3. Application
  4. Wear Parts

The five station wire prefeeding machine feeds the wire gently and continuously to the active wire storage, while the intake of the fully automatic wire harness processing machine takes the wire out of the storage in order to further processing, the wire is led under constant tension for trouble-free feeding.
It features 5 wire feeding reels which driven by 5 independent motors, each of the 5 reels is able to work individually, the moveable dancer pulley allows the prefeeder to easily respond to the typical intermittent starting and stopping actions associated with automatic wire processing machines.


Wire Reel Loose Wire

Scope of Application: wire reel or loose coil
Available Wire Diameter: Φ0.5~4mm
Ribbon Cable Max. Width: 25mm
Wire Spool Diameter: Max. 350mm
Wire Spool Width: Max. 250mm
Wire Spool Weight: Max. 20Kg
Wire Feeding Speed:
Storage Capacity: about 1m
Power Supply: 220V 50/60Hz
Net. Weight: 130Kg
Dimensions: 900×800×1250mm
