Pneumatic Crimping Applicator for Side Feed Terminals

  1. Description
  2. Specification
  3. Application
  4. Wear Parts
This crimp applicator is suitable for use on automatic wire processing systems as well as on bench-top presses for side feed terminals with either metal, plastic or mylar tape carrier strips. It can provide a more consistent, higher quality termination. In the world of wire processing equipment, crimp applicators are like offensive linemen on a football team, they're the unsung heroes that perform in the trenches out of the limelight.
Terminal Type: side feed reeled terminals
Terminal Pitch: Max. 30mm
Terminal Thickness: 1.2mm
Feed Type: pneumatic feed
Wire Cross Section: 10mm2 (AWG 8)
Press Stroke: 40mm
Crimping Height (Shut Height): 135.8mm
Crimp Height Adjustment: 0.01mm resolution, 2.7mm range
Net. Weight: 5Kg
Dimension: 160×110×150mm
