Belt-driven Cable Wire Cutting and Stripping Machine

Model
KS-W001
Brand
KINGSING
Price
Inquiry
  1. Description
  2. Specification
  3. Application
  4. Wear Parts

The automatic cable wire stripping machine adopts belts to feed the wire instead of normal steel rollers, there is no damage to the wire surface during feeding and stripping process. The output rollers is able to lift up automatically while stripping the wire head, so as to reduce the stripping resistance and greatly increase the availbe wire head stripping length range.

The feeding roller distance and pressure can be set in program directly, so there is no need to adjust any screws when you change different wire sizes! You can store all the parameter settings for different wires in different file numbers, so that you can call it out immediately when changing wires.

This machine is able to process Max. 3 layers cables, each layer's stripping length can be set in touch screen. This function is also very helpful for stripping multi-core round cables, it can pretect the inside core wires from hurting by blade edge while removing the outside jacket.

The 1.5 meters conveyor belt is an optional device, it can keep the finished wires straight and tidy in the wire collection plate, we recomend you choose this optional conveyor belt if you want to process long wires.

KINGSING
1.5m Conveyor Belt Long Stripping Length Multi-layer Stripping Half Stripping
Available Wire Size: 6-50mm2
Max. Stripping Length: Head 250mm, Tail 180mm
Cutting Length: 80-9999mm (Both side stripping)
Length Tolerance: ±(0.5+L×0.2%) (L=Cutting Length)
Memory Function: Store Max. 100 programs
Operation Interface: Color touch screen
Power Supply: 220V 50/60Hz
Net. Weight: 120Kg
Dimension: 620×580×420mm
