Automatic Heat Shrink Tubing Heat Shrinking Machine

  • Model:KS-H220
  • Net. Weight:103kg
  • Dimension:1800×860×1070mm
  1. This is an automatic heat shrinkable tube heat shrinking machine, which is widely used in the wire harness processing industry. Both of the upper and lower sides of the heating area are equiped with infrared heating tubes, so the heat shrinkable tube is heated evenly. The temperature of the heating zone can be adjusted, and the rugged design allows it to work 24 hours a day!

    KINGSING
    KINGSING
  2. This machine adopts the method of local heating, it can only heat the part of the wire containing the heat shrinkable tube, and the other parts will not be heated, which is beneficial to protect your product, especially for the occasion where the product itself is not suitable for heating.

  3. The heat shrink tube processing machine is equipped with a conveyor belt, the operator only needs to throw the wires on the conveyor belt, then the wire can be sent to the heating area for heating, it helps to keep the operator away from the risk of scalding. When the product is relatively long, an optional auxiliary feeder can also be selected.

    KINGSING
    KINGSINGKINGSING
  4. It is suitable for heating various types of heat-shrinkable tubes, such as: PE heat-shrinkable tubes, PVC heat-shrinkable tubes, double-walled heat-shrinkable tubes with glue, POF heat-shrinkable films, etc.

Download: (1) (2)
ModelKS-H220AKS-H220B
FeatureBasic ModelAdvanced Model
TEMP. Tolerance±5℃±3℃
Control SystemManual KnobDigital Adjustment
Shutdown Cooling

KS-H220A:  The cooling fan will work for 60 seconds and then shut down.

KS-H220B:  After shutdown, the cooling fan continues to work until the temperature is below 50℃.

Heating MethodInfrared heating tubes are installed on both sides with heat reflective materials inside.
Heating Area300×220mm
Max. Temperature260℃
Max. Wire OD25mm
Max. Inlet Height40mm
Max. Tube Length220mm
Conveyor Belt Width650mm
Feeding Speed1~5m/min
Power Supply380V 50/60Hz  (220V for option)
Power Rating8.9KW
Net. Weight103kg
Dimention1800×860×1070mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
