Cable Braided Shield Brushing and Twisting Machine

  • Model:KS-W021
  • Net. Weight:
  • Dimension:
  • Beautiful shape, small size, portable.

  • Exposed design for automatic clamp is easy to collect loose copper wires together.

  • Install auto wire drawing device, and wire retreat speed is adjustable.

  • Three brush heads to make sure fast straightening work.

  • The gap between brushes can be adjusted for various braided cable with different density.

  • Humanized design for waste storage area for subsequent cleaning.

  • It can brush and twist cable at the same time. The brush can work in backwards and forwards directions.

  • Adapt pure copper silent high-speed motor to ensure the machine performance steady and its long life-span.

  • Elastic clamp in this machine is suitable for different wire size and need not adjust machine by manual. It saves a lot of time.

  • The machine is equipped with elasticity wear-resisting rubber brush which is corrosion resistance and not easy deform. Twisting speed is adjustable.


Download: (1) (2)

Speed Regulating:stepless regulating

Product Function:cable shield braid brushing and twisting

Start Mode:foot pedal switch

Twisting Length Range:10~80mm

Available Cable Size:Max.8mm

Power Supply:AC 220V/50HZ

Power Rating:40W

Air Pressure:0.5~0.7Pa

Power:Gas-electric Combination

Net Weight:12Kg

Dimension(L×W×H):320mm*310mm*210mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
