Automatic Cable Winding and Cutting Machine

  • Model:KS-C0 Series
  • Net. Weight:
  • Dimension:

These wire cutting and winding machine is suitable for round wire, flat/ribbon wire, 2 pin double wire, etc. It will process the wire according to the parameters you set on the LCD touch screen, the whole producer is fast and stable. The cutting length and wire binding cycle are both easy to adjust, the previous setting parameters will be saved automatically. All of its wearing parts are designed very durable and artful, it released manual work and improved working speed as well as processing stability.

Download: (1) (2) (3) (4) (5)

Winding Cycle1 ~ 999 cycle
Winding Speed1 ~ 4 cycle / S
Available     Wire Sizeф2-7mm or ф6-10mm
Winding Inner     Diameteradjustable from 80 to 250mmadjustable from 60 to 190mm
Winding Outer     DiameterMax. 300mmMax. 260mm
Available     Wire Width10 ~ 70mm
Suitable Wire     Shaperound wire, flat/ribbon     wire, 2 pin double wire, etc.
Binding     Diameter--5 ~ 28mm / 15 ~ 40mm
Suitable     Cable Tie Length--75 ~ 135mm / 120 ~180mm
Cable Tie     Twisting Cycle--2 ~ 8 cycle
Dimension1100 x 1150 x 430mm1400 x 1150 x 430mm
Net Weight60Kg75Kg
Power SupplyAC220V 50Hz/ 110V 60Hz
Power Rating<1000W
Wire     Orderunorderedorderedunorderedordered

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
