Pneumatic Side Feed Terminal Crimp Applicator

  • Model：KS-CP30S
  • Net. Weight：
  • Dimension：
Online Inquiry
This is the latest generation crimp applicator for use in both automatic and semi-automatic crimping machines. Banded terminals of open or closed barrel construction with either metal or plastic carriers can easily be processed. This terminal crimp applicator is the ideal solution for crimping pre-insulated ferrules and Panduit Reel Smart terminals.
Terminal Type: side feed reeled terminals
Terminal Pitch: Max. 45mm
Terminal Thickness: 1.2mm
Feed Type: pneumatic feed
Wire Cross Section: 10mm2 (AWG 8)
Press Stroke: 30mm
Crimping Height (Shut Height): 119.7mm
Crimp Height Adjustment: 0.01mm resolution, 2.7mm range
Net. Weight: 4.5Kg
Dimension: 225×80×165mm
Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
