Wire Harness Circular Labeling Machine

  • Model:KS-L115C
  • Net. Weight:
  • Dimension:

This is our latest wire circular labeling machine, which is not only suitable for round wire, but also for pair twisted wire and wire harness composed of multiple wires. The operator only need to simply put the wire into the working position,then it can automatically wrap the label onto the wire without rotating the wire itself.

The machine can be equipped with an optional wire label printer, and we can supply the raw materials of wire labels, the label size can be customized according to customer requirements.


Download: (1) (2)

Labeling Accuracy: ±0.2mm;

Label Width: 5~40mm

Label Length: 10~100mm

Label Printer: optional

Max. Label Roll OD: 240mm

Max. Label Roll ID: 76mm

Capacity: 1000~1500pcs/hour

Applicable Label Thickness: 0.06mm or more

Air Source: 0.4~0.6Mpa

Power Rating: 250W

Power Supply: 220V 50/60Hz

Net. Weight: 86kg

Dimension: 580×680×1000mm

Configure Standard Positioning Ruler: 200mm

Applicable Product Size: 3~12mm(common for round wire, flat wire, twisted wire, loose wire and other products)

Label-to-label Interval: 2~3mm (the left and right edges of the label need to be 3~5mm shorter than the label backing paper)

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
