Ultra Short Wire Cutting Stripping Twisting Machine

  • Model:KS-W107
  • Net. Weight:
  • Dimension:

Automatic Double Wire Cutting Stripping and Twisting Machine KS-W107 combines the function of wire cutting stripping and twisting, one machine, multiple use. Traditional setup used to be extremely time-consuming, this stripper can store 99 sets of program in the touch screen, which you can retrieve anytime while needed. The changeover to new types of wires can be done in no time. Moreover, KS-W107 is suitable for process 2 wires simultaneously, which improved the working efficiency almost 2 times than normal types. With its flexible twisting function designing, twisting direction and tightness can be set freely, also, the twisting function can be turned on and off according to the requirements of actual operating needs by customers. It satisfies the ever tougher quality requirements in wire processing, especially for its affordable price level.

Download: (1)

Available Wire Size: 0.1 ~ 2.5mm²
Cutting Length: 0.1 ~ 999999mm
Stripping Length: Head 0.1 ~ 30mm End 0.1 ~ 60mm
Stripping Accuracy:± (0.002mm× Stripping Length)
Cutting Accuracy:± (0.002mm× Cutting Length)
Speed: 5000pcs/hour
Drive Mode: 4-wheel drive
Blade Material: Hard tungsten steel
Power Rating: 450W
Power Supply: 220V/50Hz 110V/D0Hz
Net Weight: 38Kg
Dimension: 450 × 330 × 700mm
