Industrial automation PLC, human-machine interface control, simple operation, stable operation and high efficiency.
The heat shrink tubing is automatically fed, the baking length can be freely set, and the baking position can be adjusted by the positioning device.
The production capacity can reach 300~1000 terminals/hour (depending on the speed of manual wire feeding and processing technology).
The equipment has large compatibility, and various specifications of wire materials can be processed by replacing the fixture.
The baking device adopts a screw module transmission component with a closed-loop motor to achieve high-precision positioning baking, and its baking position can be adjusted arbitrarily by digital.
The baking method adopts double heating tubes for baking up and down, which is not only efficient, but also more uniform.
Digital temperature control, as well as abnormal monitoring of the heating device and automatic protection of the heating device when the air pressure is too low, extend the service life.
Prevent operator parameter adjustment errors and the system recovers with one click.
Heat shrink tube compatible range: Ф7.0/Ф16 flat heat shrink tube
Heat shrink tube length: 10MM~100MM (optional fixture)
Baking temperature: 200°C~400°C (adjusted by thermostat)
Power Supply 220V AC 50/60HZ
Power rating: 2350W
Display: 4-inch color TFT
System control mode: PLC/touch screen
Air pressure: 5.5/6.5KPa
Operating temperature: 0°C~50°C
Operating humidity: 10%RH~90%RH (no condensation)
Cooling method: forced air cooling
Machine weight: 140KG
Dimensions (L*W*H): 950*750*1050mm
Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.
Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.
Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
