Automatic PET Weaving Mesh Tube Cutting Machine

  • Model：KS-B81H
  • Max. Width：
  • Blade Type：
  • Net. Weight：
  • Dimension：
Online Inquiry

KS-B81H is specially designed for cutting the PET weaving mesh tube. It integrates tube feeding, hot cutting and hole enlarging and finished product discharging. Fully automated operation and without human intervention. PLC and touch screen control system, easy to operate.

Adopts step motor, tube feeding is stable, and feeding length is high accurate. Integrated circuit is easy to maintenance and operate. Compared to manual cutting tools, this machine has largely improved working capacity.


Download: (1)

Tube Diameter: Ф6-30mm

Cutting Length: 0.1-9999mm

Cutting Accuracy: (±1+0.02*L) mm (L=cutting length)

Speed: 800 pcs/hour (Depends on cutting length)

Power Supply: 220V / 50Hz or 110V/60Hz (can be customized)

Air Pressure: 0.5-0.7MPa (Must be clean, dry and stable compressed air)

Heating Temperature: 0-800℃

Other functions: Tube hole enlarging

Dimensions (L × W × H): 1230*700*1300mm (Tube cutting machine) 610*470*450mm (Material holder)

Net Weight: 169KG (Tube cutting machine) 20KG (Material holder)

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.


Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
