Semi-automatic Stripping and Crimping Machine

  • Model：
  • Net. Weight：
  • Dimension：
Online Inquiry

  • Manual wire discharge, automatic triggering operation, stripping length can be flexibly adjusted, and crimping height can be flexibly set;

  • Using servo motor for crimping;

  • Multiple terminals of the same type can be expanded to be online at the same time, tubular terminals can be crimped without changing molds, and OT/UT terminals can be crimped with quick-change molds.


Power supply: AC220V 50HZ single phase

Processing range: 0.5mm2~4.0mm2; BVR, RV and other types of wires

Production efficiency: 15~18 pieces/minute

Crimping force: mold-free servo crimping 5T

Terminal type: Needle tubular/aviation pin/OT/UT pre-insulated terminal

Stripping length: 0~17mm

Terminal feeding: three-axis robotic arm + circular vibration

Detection device: terminal material shortage detection, wire in place detection

Air pressure: about 0.5~0.7Mpa

Dimensions (L×W×H): 550*730*1170mm

Note：

  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.

Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
