High-speed Flexible Hose Cutting Machine

  • Model:KS-P136C
  • Max. Width:
  • Blade Type:
  • Net. Weight:150kg
  • Dimension:850×520×1200mm

This is a high-speed pipe cutting machine, its main advantage is that the speed is very fast, it can be used with the extruder to cut pipes online, and it is also suitable for occasions that need to increase production capacity.

The cutting knife of this machine is a utility blade, which can be easily purchased around the world, it can greatly reduce the cost of use.

KINGSING

The belt feeding wheel is driven by a high-precision stepping motor, and the contact area between the belt and the tube is large, which can effectively prevent slippage during the feeding process, so it can ensure high feeding accuracy.

Download: (1)

Power Supply:220V  50~60HZ

Cutter Power:2.0KW servo motor

Power:2.3KW

Cutting diameter:Φ1~Φ36mm hose

Length error:±0.2~0.5%(depending on the tube material)

Speed:50~400 pieces/minute (depending on the length)

Dimension:850*520*1200mm

Weight:150KG

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
