Multi-core Sheath Wire Stripping, Twisting and Tinning Machine

  • Model：KS-W22H
  • Net. Weight：300kg
  • Dimension：1100×630×1300mm
Online Inquiry

This series is a semi-automatic wire stripping, twisting and tinning machine, suitable for processing various double wires, multi-core sheathed wires, rubber wires, etc. This machine needs to be customized according to the product, and there are multiple sub-models to choose from (see technical parameters for details). For double wires, it can realize automatic wire separation, wire stripping, twisting, and tinning; for multi-core sheathed wires, it can realize functions such as automatic sheath stripping, core wire stripping, twisting, tinning, and head trimming.

Download: (1) (2) (3)
ModelKS-W22HAKS-W22HBKS-W22HCKS-W22HD
Applicable wiredouble wiresSheathed wire within 3 cores4~6 core sheathed wireRubber wire within 3 cores
Sheath stripping≤50mm (splitting wire length)

≤80mm（Can be customized）

≤50mm（Can be customized）

≤50mm（Can be customized）

Applicable wire: double wire, flat sheathed wire, round sheathed wire

Applicable wire diameter: AWG28~16 (0.1~1.0mm2)

Tinning length: 2~9mm

Production efficiency: 1600~2000 pieces/hour

Operation interface: color touch screen

Air pressure requirement: 0.5~0.7Mpa

Working voltage: 220V 50/60Hz

Net weight: 300kg

Dimensions: 1100*630*1300mm

Note：

  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.

Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
