Ribbon Cable Stripping and Splitting Machine

  • Model:KS-W110
  • Net. Weight:
  • Dimension:

Jacket cable/wire Cutting and Stripping Machine KS-W110 is specially manufactured for flat cable/wire with a cross section of up to 2mm², 99 sets of memory program enable KS-W110 to operate without setting the value repeatedly. All the setting can be done through LCD touch screen in seconds. The straightforward display provides information in the selected language about the current processing status, very visualized. Excellent mechanical design and superior tungsten steel blade guarantee zero damage of wire/cable conductor. Moreover, it is a reasonably priced high-speed stripping machine, and it has become one of the most popular stripping machines both domestic and abroad.

Download: (1)

Available Wire Size: 0.1 ~ 2.0mm²
Cutting Length: 0.1 ~ 999999mm
Stripping Length:  Head 30mm, End 60mm
Stripping Accuracy:± (0.002mm× Stripping Length)
Cutting Accuracy:± (0.002mm× Cutting Length)
Speed: 3000 ~ 7000pcs/hour
Drive Mode: 4-wheel drive
Display: LCD display with English menu
Blade Material: Hard tungsten steel
Memory Function: Max. 99 group of programs
Power Rating: 450W
Power Supply: 220V/50Hz 110V/D0Hz
Net Weight: 42Kg
Dimension: 500 × 475 × 335mm
