1、This series of coaxial cable stripping machines includes 3 sub-models, which are suitable for processing various coaxial cables, automotive cables, medical cables, high temperature wires, new energy wires, etc.It uses 4 pieces of high-precision tungsten steel blades to rotate and strip wires, which is more advantageous when stripping thick wires. The rotating blade can cut the stripping position 360 degrees, the stripping mouth is smooth , the stripping length is precise, the cutting accuracy can reach 0.01mm, and the inner layer will not be damaged.
2、Color touch screen operation interface, parameter setting is intuitive and easy to understand. It can be stripped in up to 9 layers, and the cutting depth and stripping length of each layer can be freely set in the program. For example, when stripping a coaxial cable, the outer layer, braided layer, and core wire can be stripped to different lengths. Up to 99 groups of programs can be saved, and the processing parameters of different wire materials can be saved in different program numbers. When switching wire materials, the corresponding parameters can be called out with one key without mechanical adjustment.
|Applicable wire diameter||Φ3~18mm||Φ1.13~15mm||Φ1.37~23mm|
|Maximum stripping length||90mm||85mm||80mm|
Number of blades: 4 pieces
Program minimum setting unit: 0.01mm
Maximum stripping layers: 9 layers
Production efficiency: 400~600 pieces/hour
Program memory function: up to 99 groups of programs can be saved
Working voltage: AC 220/110V 50/60Hz
Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
