Crimp Applicator for End Feed Reeled Terminals

  • Model：KS-CM30R
  • Net. Weight：
  • Dimension：
Online Inquiry
The crimping applicator with quick change system is made for crimping rear feed belted terminals on wires with cross sections up to 6mm2, it provides the most efficient method of applying chain terminals to a pre-stripped wire when installed in a semi-automatic or full-automatic terminal crimping machine.
Terminal Type: rear feed reeled terminals
Terminal Pitch: Max. 27mm
Terminal Thickness: 1.2mm
Feed Type: mechanical feed
Wire Cross Section: 10mm2 (AWG 8)
Press Stroke: 30mm
Crimping Height (Shut Height): 119.7mm
Crimp Height Adjustment: 0.01mm resolution, 2.7mm range
Net. Weight: 4.5Kg
Dimension: 225×85×165mm
Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
