Double -sided thermal suite heating shrinking machine

  • Model:
  • Net. Weight:
  • Dimension:

Heat shrink tube heating machine (double transmission does not damage the wire), especially suitable for the processing needs of heat shrink tubes by wire harness processing enterprises, double-sided heating, multi-angle anti-heat materials make the heat shrink tubes evenly heated, heating temperature, conveying speed, stepless adjustment, suitable for heat shrink tubes of any length. Double-sided heat shrink tube heating and shrinking machine, double-sided heating temperature controllable, single-sided and double-sided heating optional, adjustable heating zone width, multi-angle anti-heat materials make the heat shrink tubes evenly heated, heating temperature, conveying speed, stepless adjustment, suitable for heat shrink tubes of any length.

  • Connection and shrinkage of PE heat shrink tubes, PVC heat shrink tubes, and double-wall heat shrink tubes with glue.

  • Heat shrinkage of polyvinyl chloride tubes.

  • Heat shrinkage of capacitors, batteries, wire terminals, heat shrink tubing/films, etc.


Conveying speed: <200mm

Heating width: <120mm

Heating power: 3.2KW

Power supply: 220V/50HZ

Wire feeding speed: 1~5m/min

Net weight: 73kg

Machine power: 3.4KW

Heating method: thermal radiation

Machine size: 1200*420*445mm

Heating tube power: 3.2KW

Conveying motor power: 25W

Max. conveyor belt width: 200mm

Wire diameter: <25mm

Heatable sleeve length: <120mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
