Fully Automatic Double Wire Stripping and Twisting Machine

  • Model:KS-W108
  • Net. Weight:
  • Dimension:

Double Wire Twisting Machine KS-W108 delivers an extraordinarily wide range of applications, simple handling and increased productivity. KS-W108 is designed to process 2 wires simultaneously, improved working efficiency by 2 times compared to ordinary ones. Support multiple working mode, such as double wire cutting, stripping and twisting, ultra-short wire cutting, stripping and twisting, jacket wire cutting, stripping and twisting, multi place middle stripping, etc. All process parameters can be saved along in the touch screen. The customer has his choice of rubber rollers or iron rollers depending on his requirements. This stripping machine is equipped with superior tungsten steel blades/knife, guarantee smooth and stable working performance.

Download: (1)

Available Wire Size: 0.1 ~ 4.5mm² (AWG ~ AWG)
Cutting Length: 0.1 ~ 999999mm
Stripping Length: mm
Stripping Accuracy:± (0.002mm× Stripping Length)
Cutting Accuracy:± (0.002mm× Cutting Length)
Speed: 5000pcs/hour
Display: LCD screen with English menu.
Drive Mode: 4-wheel drives
Blade Material: Hard tungsten steel
Power Rating: 450W
Power Supply: 220V/50Hz 110V/D0Hz
Net Weight: 38Kg
Dimension: 450 × 330 × 700mm
