Double Wire High Precision Stripping Machine

  • Model:KS-W112
  • Net. Weight:
  • Dimension:

Fully automatic wire harness processing will become increasingly important in the future. After all, the full automation of these processes, completely release of manual work, is the only way to assure maximum quality and efficiency. Automatic Double Wire Cutting and Stripping Machine KS-W112 has precise and outstanding quality, excellent value for the money, and ultra-easy operations. KS-W112 is designed to strip double wire (2 wires), which improved the output around 1.5 times than normal machine.This machine supports full stripping, half stripping and middle stripping, you may also choose cutting without any form of stripping function. With its competitive price, it has quickly become one of our most popular type of wire stripping machines. Professional for short and thin wire processing, and it has the ability to cut and stripping very short wires, for example, total wire length 3mm with both ends 1mm stripped.

Download: (1) (2)

Available Wire Size: 0.1 ~ 2.5mm² (AWG32 ~ AWG13)
Cutting Length: 0.1 ~ 999999mm
Stripping Length: 30mm
Stripping Accuracy:± (0.002mm× Stripping Length)
Cutting Accuracy:± (0.002mm× Cutting Length)
Ultra Short Stripping: 34mm
Speed: 3000 ~ 7000pcs/hour
Drive Mode: 4-wheel drive
Display: LCD display with English menu
Blade Material: Hard tungsten steel
Memory Function: Max. 99 group of programs
Power Rating: 450W
Power Supply: 220V/50Hz 110V/60Hz
Net Weight: 38Kg
Dimension: 450 × 330 × 700mm
