Insulated Spade Terminal（apply in flexible wire）

  • Model：SVN5.5-4S-90D-D
  • Net. Weight：
  • Dimension：
Online Inquiry
Item NoCable Size AWG
Thickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)Dimensions(mm)Color
W L E DФ
SVN1.25-3-90D0.5-1.5（22-16）0.7519A #43.25.727.710.54.0Red
SVN1.25-3.5S-90D #63.75.7
SVN1.25-3.5L-90D #63.76.4
SVN1.25-4S-90D
 #84.36.4
SVN1.25-4M-90D #84.37.2
SVN1.25-4L-90D #84.38.1
SVN1.25-5S-90D #105.38.1
SVN1.25-5L-90D #105.39.5
SVN1.25-6S-90D1/46.49.5
SVN1.25-6L-90D1/46.412.0
Item NoCable Size AWG
Thickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)Dimensions(mm)Color
W L E DФ
SVN2-3-90D1.5-2.5（16-14）0.827A #43.221.721.310.54.5Blue
SVN2-3.5S-90D #63.721.3
SVN2-3.5L-90D #63.721.3
SVN2-4S-90D
 #84.321.3
SVN2-4M-90D #84.321.3
SVN2-4L-90D #84.321.3
SVN2-5S-90D #105.3

21.3

SVN2-5L-90D #105.321.3
SVN2-6S-90D1/46.421.3
SVN2-6L-90D1/46.412.027.6
Item NoCable Size AWG
Thickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)Dimensions(mm)Color
W L E DФ
SVN3.5-3-90D2.5-4（14-12）1.037A #43.25.725.514.26.4Black
SVN3.5-4S-90D #84.37.225.5
SVN3.5-4-90D #84.38.025.5
SVN3.5-5-90D #105.38.025.5
SVN3.5-6-90D1/46.412.028.5
Item NoCable Size AWG
Thickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)Dimensions(mm)Color
W L E DФ
SVN5.5-3.5-90D4-6（12-10）1.048A #63.77.225.514.27.0Yellow
SVN5.5-4S-90D #84.38.326.8
SVN5.5-4L-90D #84.39.026.8
SVN5.5-5-90D #105.39.026.8
SVN5.5-6S-90D1/46.49.026.8
SVN5.5-6L-90D1/46.412.032.8
SVN5.5-8-90D5/168.414.031.8
