Wire Harness Flag Labeling with Colour Printing Machine

  • Model：KS-L132F
  • Net. Weight：
  • Dimension：
Online Inquiry
Download: (1)

Lable type: Flag shape

Wire Diameter: 3~12mm

Label Roll Size: 30~108mm

Label Length: 20~130mm(Can be customized)

Label Width: 5~20mm(Can be customized)

Labeling Accuracy: ±0.2mm

Label Category: Fine paper, Plain label, Matte label, Synthetic label, Wristband, Glossy label

Label Type: Continuous paper (with/without black marks), Label roll paper, Die-cut labelpaper (with/without black marks), List band

Print Ink: C, M, Y, K four colors split type ink

Capacity: 1000~1500pcs/hour(depends on the operation proficiency)

Operate Temperature: 15~35°C

Humidity: 30%~80%RH (No condensation)

Rated Power: 300W

Power supply: AC220V 50Hz/60Hz

Air supply: 0.5~0.7MPa (Must be clean, dry and stable compressed air)

Net Weight: 94KG

Dimension(LxWxH): 630x880x1360mm

Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
