This single head Automatic Wire Twisting and Tinning Machine,
can send solder wire
add flux automatically
with its perfect twisting effect
high accuracy
wide application
it became the most effective machine for electronic wire harness processing industry.
The user can choose the real-time terminal pressuremanagement system, which will alarm when the terminal crimping pressure is abnormal, therefore, the processing quality is under 100 percent control.
Wire Size: AWG16 - AWG30
Stripping Length: 0 - 20mm(wire end stripping L + wire head stripping L ≤20mm)
Twisting Length：3 - 10mm
Max. Wire Tinning Depth: 15mm
Cutting Length：30 - 800mm (Other length can be customized)
Cutting Accuracy: ±（0.1 + 0.002×L）mm （L=cutting length）
Crimping Force: 2Ton （customizable）
Power Rating: 1500W
Speed: 5000 -8000 pcs/h
Air Supply: 0.4 - 0.6MPa
Detection device: terminal, crimping error, wire knotting, air supply error, mechanical error, etc.
Power Supply: 220V/50Hz
Net. Weight: 390Kg
Gross Weight: 430Kg
Dimension: 700 × 800 × 1900mm
Note：
The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.
Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
