This is a free-standing, electric-demand wire prefeeder designed to pull wire and cable from reels weighing up to 20kg and provide a constant tension to downstream wire processing machines. A moveable dancer pulley allows the wire pre-feeder to easily respond to the typical intermittent starting and stopping actions associated with automatic wire processing machines.
Small size, save space;
Excellent price/performance ratio;
Designed by human structural mechanics to reduce fatigue strength;
Easy operation and low technical requirements for operators;
The wire feeding speed can be adjusted freely by turning the adjusting knob of the speed controller;
Both reel type wire and loose type wire can be used for this machine, the scope of application is wider;
With one-key switch function of motor forward and reverse.
Scope of Application: wire reel or loose coil
Available Wire Diameter: Φ0.5~4.0mm
Wire Spool Diameter: Max. 400mm
Wire Spool Width: Max. 195mm
Drum ID: Min.30mm
Wire Spool Weight: Max. 20Kg
Wire Feeding Speed:Max.1.2m/s,adjustable
Motor Power:150W
Power Supply: 220V 50/60Hz
Net. Weight: 30Kg
Dimensions: 900×500×930mm
Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.
Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.
Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
