Semi-automatic Power Cord Plug Crimping Machine

  • Model:KS-P315E
  • Net. Weight:1600kg
  • Dimension:1900×2700×1900mm

This is a semi-automatic 3-core power cord production line.  The plug is automatically fed by the vibrating plate, the operator only need to manually clips the cable end into the fixture, then It's able to automatically complete the following actions: strip the outside jacket, strip the core wires, adjust the color order of core wires, insert into plug and crimp.

This machine needs to be customized according to the samples. Usually, one machine is only suitable for producing one fixed product, But it is also possible to customize a machine that can support 2 different plugs without changing any accessories. The machine can be equipped with 2 sets of crimping machines and vibrating plate feeding system, the operator can choose the crimping station in the program freely, so it can be compatible with 2 different products in one machine.

Download: (1)

Available Cable: Max. 3 cores round cable

Core Wire Size: ≤1.5mm2

Capacity: 900~1200pcs/hour

Crimping Force: 4Ton

Good Rate: >99%

Power Rating: 3.5KW

Air Source: 0.5~0.8Mpa

Power Supply: AC220V/AC380V 50Hz

Net. Weight: 1600Kg

Dimension: 1900×2700×1900mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
