Heavy-duty Cable Stripper Machine

  • Model:KS-09J
  • Net. Weight:
  • Dimension:

With a high level of stripping force, KS-09J can process wires with hard insulation. It has special capabilities that go beyond stripping and cutting/shortening/trimming, allowing it to handle the most demanding tasks. Power, performance and a revisable type of pulse value are the three key features of the Fully Automatic Large Cable Cutting and Stripping Machines. KS-09J is compelling in the extremely broad range of processing they cover. Thanks to the simple, flexible controls, any type of wires can be set up quickly and easily.  The changeover to new types of cables can be done in no time. Traditional setup used to be extremely time-consuming, this stripper can store 99 sets of program in the touch screen, which you can retrieve anytime while needed.

Download: (1) (2) (3)

Available Wire Size: 0.1 ~ 90mm2
Max. Conduit Diameter: Φ22mm
Suitable Cable:2 core and 3 core power cord
Suitable Cable Diameter:4 ~10mm
Cutting Length: 0 ~ 9999mm
Stripping Length: Wire Head 0 ~ 200/ Wire End 0 ~ 80mm
Stripping Accuracy:± (0.002mm× Stripping Length)
Cutting Accuracy:± (0.002mm× Cutting Length)
Outer Jacket Stripping Length:30 ~ 100mm
Speed:400 ~ 600Pcs/h
Drive Mode: 8-wheel drive
Display: 7inch LCD display with English menu
Air Pressure: 0.4~0.6Mpa
Memory Function: Max. 40 group of programs
Power Rating: 600W
Power Supply:AC220V/50Hz  AC110V/60Hz
Net Weight:40Kg
Dimensions: 800 x 700 x 440mm

Cutting & Stripping Samples:

1. 7 core hard wire Cut & Strip sample
2. Multi-strand wire Cut & Strip sample (Half Strip VS Full Strip)
3. Sigle core hard wire Cut & Strip sample
