PCB Veneer Welding Machine

  • Model:
  • Net. Weight:
  • Dimension:

1、Index rotation mode operation;

2、Visual inspection of incoming materials, precise positioning;

3、Using high-quality soldering iron welding system, stable and efficient;

4、Independent workstations are used for welding the core wire and the braiding layer, and the size and height of the solder joints are controllable;

5、The terminal angle can be adjusted automatically, and the tolerance is less than ±10°;

6、Can automatically paste adhesive (foam).

Cutting capacity: 60-800mm

Processing diameter: 0.81-1.78mm

Cutting depth setting unit: 0.01mm

Equipment utilization rate: ≥95%

Working pressure: 0.5Pa

Yield: finished product yield ≥ 95%

Dimensions: 1900*1200*2100mm

Total power of equipment: 3KW

Weight: 1200kg

Production efficiency: 850-950pcs/H (depending on the stripping length)


  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
