Automatic Coaxial Cable Single-head Crimping and Double-head Soldering Machine

  • Model：
  • Net. Weight：
  • Dimension：
Online Inquiry

1. Deep integration of automation, informatization, and intelligent manufacturing.

2. High security, high reliability and high operability.

3. It can be connected to the back-end welding plate and automatic assembly machine.


Wire cutting capacity: A: Under single-head crimping work: 50-400

                                    B: Under double-head soldering work: 50-400

Processing diameter: 0.81-1.78mm

Cutting depth setting unit: 0.01mm

Equipment utilization rate: ≥95%

Machining accuracy: Tolerance of stripping at both ends ±0.1mm Total length tolerance ±0.5mm

Working pressure: ≥0.5Pa

Applicable working voltage: AC220V±10V

Dimensions: 1600*2000*2100mm

Power: about 4.5Kw

Weight: 1500kg

Production efficiency: 900--1200 PCS/H (depending on the stripping length)

Note：

  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.

Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
