Part No. | Cable Size A.W.G | Max Current | Thickness(mm) | Dimension(mm) | Color | |||||
W | bФ | DФ | dФ | L | F | |||||
MRFNY1.25-156 | 0.5-1.5(22-16) | 15A | 0.4 | 7.5 | 4.0 | 4.3 | 1.8 | 25.5 | 15 | Red |
MRFNY2-156 | 1.5-2.5(16-14) | 24A | 0.4 | 7.5 | 4.0 | 4.5 | 2.4 | 25.5 | 15 | Blue |
Terminal Body:Brass
Insulation:Nylon
Temperature:105℃
Plating:Tin
