Nylon Braided Hose Cutting and Taping Machine

  • Model：KS-P914T
  • Net. Weight：
  • Dimension：
Online Inquiry

KS-P914T is an automatic nylon braided hose cutting and taping machine, it automatically tapes the cutouts at both ends to prevent the nylon braid from unraveling. The taping function can also be turned off in the program, then you can use this machine to cut normal flexible hoses, such as corrugated tubes, silicon tubes, etc. Color touch screen operation interface, all parameters are intuitive and easy to understand, just simply set the cutting length and quantity, the machine can work automatically.

Download: (1)

Pipe Diameter: Ф9~Ф20mm (depends on the pipe material)

Tape Specification: Width: Max.20mm; ID: Ф32~76mm; OD:110mm (customized)

Blade Type: Cold blade

Cutting Length: Max.1000m

Cutting Accuracy: ±0.5+L x 0.002mm (L=cutting length)

Speed: 600~800 pcs/hour (Depends on cutting length and wrapping turns)

Power Supply: 220V /50Hz

Power Rating: 1000W

Program Memory: Max.100 groups of programs

Air Pressure: 0.5~0.7MPa (Must be clean, dry and stable compressed air)

Dimensions(LxWxH): 870*760*600mm

Net Weight: 174Kg

Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
