Main applications include multi-layer wire stripping for cables used in new energy, automotive, motorcycle, and aviation industries, particularly suitable for stripping outer insulation of DC harnesses such as charging gun cables, while also meeting the requirements for stripping inner core wires. The equipment features a full servo motor configuration with all parameters intelligently adjustable. The 4-blade + 4 wire guard rotary cutting mechanism ensures clean and even cuts, while the 8-blade stripping method guarantees stable insulation removal. Custom solutions for ultra-long stripping requirements are also available.
Stripping Diameter: 8-50mm
Stripping Length: 500mm (customizable)
Minimum Stripping Depth: 0.01mm
Rotary Cutting Method: 4 rotary blades + 4 wire guards
Stripping Method: Rotary blades + 4 stripping blades
Wire Clamping Device: Servo electric gripper
Operating Environment: 15-35°C with appropriate humidity
Storage Capacity: 100 programs
Display: 7-inch touchscreen
Activation Method: Foot pedal/Manual
Power: 2.5KW
Weight: Approximately 380kg
Dimensions: L1620 × W700 × H1470mm
Power Supply: AC220V 50/60Hz
Drive System: Full servo drive configuration
Optional: Physical interface for MES system integration
Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.
Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.
Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
