Features
High speed: Can cut up to 150 pieces per minute (with 50 mm length as an example).
High precision: Driven by high-accuracy stepping motors to ensure the precise accuracy of every operation.
Flat cut surface: Adopts an imported high-power, high-efficiency transducer to effortlessly cut materials of various thicknesses; the cut surface is flat, burr-free and does not fray.
Automatic operation: You only need to set the required parameters such as cutting length and quantity; all other work is completed automatically by the computer.
Fault self-diagnostics: If an abnormality occurs in the knife seat or there is no material, the system will automatically display an error code on the screen.
Automatic stop: Once the material runs out, the system will automatically stop operating.
Memory function: Automatically stores all parameters that have been set before the power is shut off.
Applicable Materials
All kinds of woven belts, velcro (hook-and-loop tape), shoelaces, zippers, labels, and various wide leather/webbing straps, etc.
| Parameter | Value |
|---|---|
| Cutting Length | 50–99999 mm |
| Cutting Speed (50 mm) | 150 pcs/min |
| Max. Cutting Width | 150 mm |
| Sound Frequency | 15K Hz |
| Recommended Air Pressure | 0.4–0.7 Mpa |
| Voltage | 110 / 220 V |
| Power | 3 kw |
| Ultrasonic Power | 2.6 kw |
| Weight | 150 kg |
| Machining Package Size (L×W×H) | 860 × 600 × 1530 mm |
Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.
Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.
Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
