Advanced Wire Cutting and Stripping Machine

  • Model：KS-W104
  • Net. Weight：
  • Dimension：
Online Inquiry

The KS-W104 is perfect for processing the High Voltage Power Cable in the industries of New Energy Motor, Power Charging Line, Electronic Control, etc.Its Max. Cut & Strip capacity reaches 120mm2.

This machine supports multi-layers stripping function at the same time.

  • KS-W104 is fitted with 8 sets of servo motors to insure powerful feeding and high level of cutting and stripping accuracy. This stripper adopts PLC control system and color touch screen to provide a simple and enjoyable operation experience, it also utilizes belt feeding design to avoid pressing marks on the cable.

  • With 4 movable rollers beside the machine feet, the machine can be moved easily and installed firmly on the ground.

  • A protection cover is added to prevent accidental injury, the machine will stop automatically after turn on the detection function in the program.

  • KS-W104 can work independently or to be integrated in wire processing line due to multiple interfaces are reserved in the program.



Features:

Fast installation and simple operation

Wide range of application covers wire, cable, tube, etc.

PLC control & Servo Motor driven allow ultimate processingeffect

Robust design allows heavy-duty wire loading and processing

Rotary blades ensure precise & efficient stripping

Durable tungsten steel cutter guarantees stable & powerfulcutting


Download: (1) (2)

Available Wire Size: 6 ~ 120mm2
Max. Conduit Diameter: Φ30mm
Cutting Length: 240mm ~ 100000mm
Stripping Length: 0 ~ 200mm
Stripping Accuracy：± 0.002 * L
Feeding Speed：0.8m/s
Drive Mode: 8-wheel drive
Display: LCD display with English menu
Power Supply：AC220V/50Hz  AC110V/60Hz
Net Weight：240Kg
Dimension: 1200 x 800 x 1300mm

Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
