The pressure adjustable wire clamp can make the multi-core in order to ensure that the core wire will not be damaged.
After cutting, stripping and crimping the terminals (the available inner core wires’ number is 2P-13P) to ensure the terminal crimping accuracy.
The crimped terminals are aligned on the same straight line (different from the fan shape), and the terminals are neat and beautiful after being inserted in o the housing insertion.
The crimping force monitor is optional.
Function:Fully automatic cutting of multi-core wires
stripping of outside jacket
stripping of core wire
both side crimping terminal
installing shrink tube and heating.
Processing range：2 cores-13 cores, outer diameter 3-7mm, inner cores 20-26 #
Cutting accuracy: Adjustment range 0.5mm + cutting length x 0.2% or less
Power Supply: AC220V 50 / 60Hz 20A
Dimension: L1450 * W900 * H1560 (mm)
Cutting length: 160-9999mm
Stripping length: Outer 30-160mm Inner 0-8mm
Crimping capacity: Standard 2TON
Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.
Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.
Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
