Wire Heating Straightening and Pay-off Machine

  • Model：KS-W2710
  • Net. Weight：
  • Dimension：
Online Inquiry

This is an automatic wire feeder with wire heating and straightening function. When the weather is cold, the wire is easy to harden and bend, which is not conducive to the stable processing of the automatic wire harness machine. Using this machine can heat the wire and soften it, and a wire straightener is installed at the outlet to straighten the wire.

Download: (1)

Input voltage: AC220V

Rated Power :600W

Maximum set temperature of temperature wire:200℃

Wire speed:7m/s

Be applicable:Wired axiscoil/discrete wire coil

Heating method:Fin hot air heating

Heating control method:PID

Dimension: 600×500×1100mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
