Four Wire Automatic Wire Stripping & Cutting Machine

  • Model：KS-09M
  • Wire Size：
  • Net. Weight：
  • Dimension：
Online Inquiry
This Four Wire Stripping and Cutting Machine is suitable for hard wire and flexible wire processing, it is able to cut and strip 2 wires from AWG8-AWG32 OR 4 wires from AWG11-AWG32 at one time.
This machine has a very simple operation system, the cutting blades are convenient to change, we provide different size of wire conduct according to customers needs, guarantee perfect stripping performance.
Advanced sensor contributes to minimum cutting and stripping tolerance, make the machine precise and reliable.
Available Core Cross-Section Range: 0.1 - 8.0mm2 (AWG8 ~ AWG32 Two wires at one time) 0.1 - 4.5.0mm2 (AWG11 ~ AWG32 Four wires at one time) title="KINGSING"
Conduit Diameter: Φ6mm
Cutting Length: 5 ~ 9999mm
Stripping Length: Head 0~35mm, Tail 0~15mm
Memory Function: Can store Max. 99 group programs
Max. Middle Stripping Section: 11 Sections
Cutting Tolerance: ±(0.002×L) （L=Cutting Length)
Speed: 10000~25000pcs/hour
Display Way: LCD display with English menu
Drive Mode: Six wheel drives
Blade Material: Hard tungsten steel
Power Supply: 220V/50Hz 110V/60Hz
Power Rating: 300W
Weight: 35Kg
Dimension: 420 × 390 × 280mm
Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
