Automatic PCB Shrapnel Wire Welding Sub-board Packaging Line

  • Model：
  • Net. Weight：
  • Dimension：
Online Inquiry

Mainly realize the hair clipper PCB board welding shrapnel, welding line, sub-panel, packing, sealing, labeling function.

Automatic board loading machine on the PCB board, ICT test, open and close the carrier cover 1, PCB board flip 1, PCB board sweep code into the carrier, shrapnel feeding, core wire stripping and tinning into the carrier, wave soldering to connect the core wire, carrier cache, open and close the carrier cover 2, carrier reflux, PCB board flip 2, folding & loading tool, PCB board scanning, CCD detection of soldering joints, finished product loading, scanning and sealing boxes.

KINGSING

Speed: 1000PCS/H

Crop Rate: 90%

Production Yield: 98% or more


Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
