Ribbon Cable Cutting and Stripping Machine

  • Model：KS-09E
  • Net. Weight：
  • Dimension：
Online Inquiry

To achieve efficient,economical production, you need high performance machinery that matches your requirements.

Kingsing Machinery has developed just that for you, with its wide processing range of different wire and cable.

KS-09E is designed for flat cables/wires, shrinkable tubes, and other flat material, it supports full stripping, half stripping and middle stripping, you may also choose cutting without any form of stripping function. The feeding parts is customized according to your wire size to allow gentle and smooth feeding without any damage to the wire. Fast changeover between different specifications of wires make this machine timesaving and convenient. 99 sets of data storage function in the LCD touch screen eliminate any input mistakes. This stripping machine is equipped with superior tungsten steel blades/knife, guarantee smooth and stable working performance.


Download: (1) (2)

Available Core Cross-Section Range: 0.1 - 4.5mm2 (AWG12 - AWG32)
Max.Width for Flat Cable: 18mm (normally 18 pins)
Cutting Length: 5 ~ 9999mm
Stripping Length: Head 0~35mm, End 0~15mm
Memory Function: Can store Max. 99 group programs
Max.Middle Stripping Section: 11
Stripping Accuracy：± (0.002mm×Stripping Length)
Cutting Accuracy：± (0.002mm× Cutting Length
Speed:3000~7000pcs/hour
Drive Mode: 4-wheel drive
Display:LCD display with English menu
Blade Material: Hard tungsten steel
Power Rating: 220W
Power Supply: 220V/50Hz 110V/60Hz
Net Weight:35Kg
Dimension:390 × 350 × 255mm


Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
