Automatic Cable Stripping Cutting Machine

  • Model:KS-W612
  • Net. Weight:
  • Dimension:
  1. KS-W612 installed 6 sets of step motors, each of the 4 feeding rollers are driven by separate step motor to guarantee high level of wire cutting and stripping accuracy.

    The blade unit adopts gear driven principle, stable and powerful, capable for stripping Max. 12mm2 BVR multi-strands wires or jacket cable.

  2. Extraordinary program function to allow KS-W612 to switchover between various kinds of working modes, such as long wire mode, short wire mode, jacket cable mode, etc. This machine has 99 sets of memory function which is used to store different parameters for reuse.

  3. Conveyor belt can be matched with this machine to collect wires after processing. Normally, the conveyor belt is suggested while cutting length is longer than 0.5m.

Download: (1) (2)

Available Wire Size: 1.0 ~ 16.0mm2(AWG18 ~ AWG6)

Cutting Length: 0.1 ~ 100000mm

Min. Glue Length: 80mm

Stripping Length: Head 0~45mm, End 0~45mm

Max. Middle Stripping Section: 15 places

Memory Function: Max. 100 group of programs

Stripping Accuracy:± (0.002mm× Stripping Length)

Cutting Accuracy:± (0.002mm× Cutting Length)

Speed: 5000~7000pcs/hour

Drive Mode: 4-wheel drive

Display: LCD display with English menu

Blade Material: Hard tungsten steel

Power Supply: 220V/50Hz 110V/60Hz

Net Weight: 35Kg

Dimension: 420 x 470 x 290mm

Note:

  • In the case of extremely hard, tough wires, special requirements, processing may not be possible even within the cross section range. In case of doubt, KINGSING will happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
