This is a fully automatic double wire combination crimping and inserting sheathing machine, which can process 2 different wires at the same time. After cutting and stripping, crimp the two wires into one terminal, and insert the stripped and crimped terminals at the other end into the insulating sheath. A total of 2 terminals are crimped, and an insulating sheath is inserted. The insulating sheath is automatically fed through the vibrating plate. After the terminal crimping is completed, the insulating sheath is automatically pushed onto the terminal.
Adopting the concept of modular flexible design, one machine can easily process many different products, and each functional module can be opened or closed freely in the program. For example, the insertion sheath function can be deactivated. When replacing the terminal and the insulating sheath, it is only necessary to replace the corresponding crimping die, vibrating plate feeding system and the corresponding inserting sheath jig. The use of the machine is flexible. After the current product is produced, it will not cause idle waste of the machine, and it can be easily switched to produce other products.
Both the wire cutting and stripping and translation mechanism are driven by high-precision servo motors, and the cutting blade adopts a positive and negative screw structure, with high stripping precision. This machine uses a translation mechanism to replace the traditional rotation mechanism. The wire is always kept straight during the processing process, and the positioning is accurate, which effectively solves the instability problem caused by the bending of the wire, and can easily handle various high-standard wire processing.
The terminal crimping machine is integrally formed of ductile iron. The whole machine has strong rigidity and stable crimping height. It can be equipped with a terminal pressure monitor to monitor the pressure curve changes of each crimping process in real time. When the pressure is abnormal, it can automatically alarm and stop. In addition, a visual inspection system can also be selected to inspect the appearance and size after crimping to ensure product quality. The standard terminal crimping machine is driven by a variable frequency motor, and a servo terminal crimping machine can also be selected.
Color touch screen operation interface, parameter setting is intuitive and easy to understand, the program memory function can save the processing parameters of different products in the database, when switching products, you can call out the corresponding processing parameters with one key, saving debugging time. In addition, it can also be equipped with a computer industrial control system that supports MES connection, with a built-in network interface, which can be connected to the MES system through a local area network, to realize remote reading or setting of parameters, remote production tasks and other functions.
Applicable wire diameter: AWG24~14 (0.2~2.5mm2)
Cutting length: 65~3000mm (can be customized)
Stripping length: ≤10mm (can be customized)
Cutting accuracy: ±(0.5+L*2‰) L=cutting length
Positioning accuracy of heat shrink tube: ±0.5mm
Maximum pressure: 2T (3T models can be customized)
Crimping stroke: 30mm (40mm stroke model can be customized)
Applicable terminals: cross-feed terminals, direct-feed terminals, flag-shaped terminals, etc.
Production efficiency: 1500 pieces/hour (insert sheath)
Air pressure requirement: 0.5~0.8Mpa
Rated power: 2000W
Working voltage: 220V 50/60Hz (110V can be customized)
Optional configuration: long wire conveyor belt, safety shield, terminal pressure monitor, visual inspection system, servo terminal machine, computer industrial control system
