This advanced fully automatic wire processing machine combines the functionality of two separate machines — a dual-end tinning machine and a tinning-and-crimping machine — into one compact, high-performance unit. It supports flexible configurations: dual-end tinning, or single-end tinning with another crimping, giving manufacturers maximum versatility for diverse wire harness applications.
By replacing the need for two individual machines, this all-in-one solution significantly reduces equipment footprint, operational complexity, and initial investment. Ideal for high-volume production environments in automotive, electronics, and industrial automation, it delivers seamless integration of cutting, stripping, twisting, tinning, and terminal crimping processes.
With a processing capacity of 5,000 pieces per hour and comprehensive safety detection (air pressure, wire presence, crimp quality), this machine maximizes efficiency, reduces labor costs, and enhances production consistency — all at a superior cost-performance ratio. Investing in one machine means higher productivity, lower TCO, and accelerated workflow optimization.
| Feature | Specification |
|---|---|
| Wire Range | AWG18# – AWG30# |
| Processing Capability | 5 wires simultaneously |
| Cutting Length | 20 – 1000 mm (customizable) |
| Stripping Length | Max. 15 mm |
| Production Capacity | 4,000 – 6,000 pcs/hour (varies by wire) |
| Cutting Accuracy | 0.1 × (0.1 + 0.005 × L) mm (L is cutting length) |
| Crimping Force | 1.5 Ton |
| Power Supply | AC 220 V / 50 Hz (110 V customizable) |
| Air Pressure Requirement | 0.5 – 0.7 MPa (clean, dry, stable air required) |
| Power Rating | 3 KW |
| Net Weight | 434 KG |
| Dimensions (L × W × H) | 2950 × 1020 × 1900 mm |
| Detection Functions | Air pressure, Lack of wire, Lack of terminal, Poor crimping |
Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.
Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.
Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
