Ultrasonic Tape Cutting and Hole Punching Machine

  • Model：KS-U200P
  • Max. Width：
  • Blade Type：
  • Net. Weight：
  • Dimension：
Online Inquiry

  • Robust & Reliable: The machine is designed for durability and dependability in various industrial applications.

  • Excellent Price/Performance Ratio: Offers great value for money with competitive pricing and superior performance.

  • Simple Operation: Users can start operating the machine quickly without needing any prior training.

  • Computer-Programmed Length Adjustment: Allows for precise control and adjustment of length data through computerized settings.

  • Efficiency Improvement: Enhances productivity, improves product quality, and reduces labor costs.

  • Material-Deficient Stop Function: Automatically halts operation when materials are insufficient, preventing wastage.

  • Adjustable Feeding Roller Pressure: Customizable pressure settings ensure optimal feeding effects.

  • Integrated Tape Cutting & Hole Punching: This multi-functional machine can perform hole punching, tape cutting, continuous hole punching, tape cutting, and optional coiling.

  • Ultrasonic Cutting & Punching Method: Delivers smooth incisions without rough edges or loose selvedges.

  • PLC and HMI Control System: Equipped with advanced control technology, allowing easy and fast configuration of cutting and punching parameters via a user-friendly interface.


Download: (1)

Functions: Cutting and hole punching

Cutting Width: Max.160mm

Cutting Length: 1~99999mm

Power Rating: 4.5KW

Ultrasonic Frequency: 15KHz/18KHz

Speed: 100pcs/min (depends on the cutting length)

Air Pressure: 0.5~0.7MPa

Power Supply: AC220V 50Hz

Operation Temperature: 0~40℃

Environment Humidity: 30%~80%RH (No condensation at 40℃ )

Net Weight: 200Kg

Dimension(LxWxH): 850x650x1400mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.


Important Notes:

  1. Product Updates: Images and videos displayed may differ from current products due to ongoing design improvements and updates. The actual delivered product shall prevail in case of any discrepancy.

  2. Optional Accessories: Some accessories and components shown in product photos/videos are optional configurations and not included in the standard package. Please order these items separately if required.

  3. Technical Parameters: Specifications are for reference only. Equipment suitability depends on actual working conditions, not just parameter comparison. Please consult us to confirm compatibility for your specific application.
