Fully Automatic 2-side Crimping Machine with Twisted Pair Function

  • Model:KS-T1065
  • Brand:KINGSING
  • Price:

Full-automatic Twisted-pair Terminal Crimping Machine KS-T1065 belongs to the latest series of automatic crimping machine which is controlled by color display screen. Wire cutting length, stripping knife value, stripping length, stripping depth all can be adjusted in the main screen. Precision parts are driven by servo motor and screw slide rail. Moreover, high-quality pneumatic elements and various practical verification units ensure high-precision crimping features for KS-T1065. In addition, a wide range of applicators can be applied in terminal crimping machine, for instance, OTP transversal and longitudinal applicators. Last but not least, wire detection, air pressure detection, machine failure all can be displayed and controlled in the main screen which means improving production efficiency largely and avoid wasting time in detecting machine errors.

 Stable performance and low failures;

 Reasonable space design and centralized functions;

 Designed by human structural mechanics to reduce fatigue strength;

 Precision parts are driven by servo motor and screw slide rail;

 a wide range of applicators can be applied in terminal crimping machine;

 wire detection, air pressure detection, machine failure all can be displayed and controlled in the main screen.


Model

KS-T1065

Available wire diameter

0.3-0.8mm (20-28AWG)

Cutting length

10-890mm (0.39-35.04in)

Stripping length

0-7mm (0-0.28in)

Crimping capacity

2T

Air pressure

0.5-0.7Mpa (5-7bar)

Power supply

AC 220V/50HZ

Power rating

3500W

Net Weight

Main machine: 550Kg (1212.54lbs) Conveying belt: 50Kg (110.23lbs)

Dimension

Main machine: 1500(L)*1080(W)*1650(H)mm 59.06(L)*42.52(W)*64.96(H)in

Conveying belt: 3420(L)*770(W)*1160(H)mm 134.65(L)*30.31(W)*45.67(H)in
